STRUCTURAL  DESIGN SOFTWARE That has stood the test of time

Digital Canal provides powerful and professional structural engineering and design software, and structural analysis software. These structural engineering software solutions have over 30 years of proven reliability.

"Digital Canal's Utility Library is the best value in the industry".

Joe Carri, SE
Carri Construction


Structural Design Software Overview

Utility Library

A suite of software modules, including Steel Design, Retaining Wall, Concrete Beam Design, Concrete Column Design, Masonry Wall, Timber Design, Wind Analysis, Spread Footing Design, Multiple Load Footing Design, Composite Steel Design, Shear Wall Analysis, Aluminum Design, Flat Slab Analysis, Static Pile Analysis, Pile Group Analysis and General Section Properties.

Retaining Wall

Retaining Wall quickly and easily designs and checks retaining wall systems, including the wall, footing toe and heel and a footing key if necessary.

Steel Design

Steel Design software that easily designs or checks steel beams, columns and single span beam- columns using the ASD and LRFD standards.

Concrete Beam Design

Concrete Design software that designs one-way flexural members, including beams, one-way slabs and joists.

Timber Design

Design or check any continuous beam or column using the latest building codes (NDS 05, IBC 06, ASCE 05) in just a couple of minutes. Unlimited load and support conditions, automatic load generation and much more…

Static Pile Analysis

Perform vertical and lateral soil-structure interaction analyses for anything from a fence post to a deep pile.  Advanced features include plastic behavior of the soil, skin friction and lateral subgrade reaction that varies with depth.

VersaFrame

VersaFrame has all the features needed to 'get the job done' without becoming overly complex - keeping you in total control. Key features include a sparse matrix solver, automatic area load distribution, fluid loads, load patterning, moving loads, reinforced concrete design, steel design, frequency analysis, P-delta analysis, geometry generator, member elements, plate elements, brick elements and much more.

Structural Expert Library

A suite of software modules, including Steel Design, Retaining Wall, Concrete Beam Design, Concrete Column Design, Masonry Wall, Timber Design, Wind Analysis, Spread Footing Design, Multiple Load Footing Design, Composite Steel Design, Shear Wall Analysis, Aluminum Design, Flat Slab Analysis, Static Pile Analysis, Pile Group Analysis, General Section Properties AND VersaFrame or Frame Analysis.

Masonry Wall

Masonry Wall is a design tool for the design of masonry bearing walls, walls that are subject to axial and transverse loads.

Composite Steel

Design or check encased and composite beams using ASD and LRFD design codes.  Beams can be designed for full or partial composite action.

Concrete Column Design

Concrete Design software that will design or check concrete columns for axial tension, compression and biaxial moments.

Spread Footing

With Spread Footing, footings for hundreds of columns can be designed in less than an hour.

Pile Group Analysis

Analyze a group of piles for loads in any direction using the same advanced soil-structure model used in the Static Pile program. Piles may be located at different elevations and be battered independently.

Frame Analysis and Design

Our Frame Analysis software is the only frame analysis and design program that is truly integrated with AutoCAD.  At the heart of Frame Analysis and Design is the 30+ years proven STRAAD Finite Element engine.

Pile Cap

With the Pile Cap program, analyze any pile arrangement and design the pile cap accordingly, including cap thickness, steel requirements, and rebar spacing.

Wind Analysis

Wind software designed to conveniently calculate design wind pressures using ASCE's "Minimum Design Loads for Buildings and Other Structures".

Shear Wall Analysis

Analyze a building which is laterally supported by shear walls for the shears and moments in each of the shear walls.

Aluminum Design

Design or check aluminum members for axial loads, biaxial bending and deflections.  Supported shapes include wide flanges, tubes, angles, channels, Tees, pipes and double angles.

Flat Slab Analysis & Design

Analyze and design flat slab or waffle slab floors.  Flat slabs may have drop panels at columns and columns may have capitals.

Multiple Load Footing

With the Multiple Load Footing program, define combined trapezoidal, strap, or rectangular footings with multiple loads.

General Section Properties

Calculate the centroidal axis locations, moments of inertia, radius of gyration, section moduli and product moment of inertia for virtually any shape.

StrucPro Drafting/Detailing

StrucPro is available for AutoCAD 14, 2000, 2002, 2004, 2005, 2006, 2007 and 2008.  Using StrucPro is similar to using a library of AutoCAD blocks; however, StrucPro’s parametric capabilities provide the user much more speed, power and flexibility.
